4G Positioning Collar S503

Suitable for positioning and health monitoring of livestock such as free range cattle, sheep, camels, etc

The collar adopts a combination of Beidou/GPS positioning and 4G communication technology, which can accurately collect the location information of livestock under low-power conditions
After wearing the neck of a cow or sheep, position information and exercise data can be collected and uploaded to a cloud server
This collar uses a 3-axis acceleration sensor to measure the number of steps taken by cattle and sheep per hour, and the health and estrus status of cattle and sheep can be calculated based on the change in step count
Product Features

Long communication distance 组 2.png

            Using 4G communication technology, the communication

distance is far and unrestricted

Reusable, long-lasting battery life 组 2.png

           The battery is replaceable, with long-lasting endurance and

low maintenance costs in the later stage

组 2.png Communication stability

          Adopting 4G communication technology, with strong stability

组 2.png Easy to install

          Universal structural design, the length can be adjusted before

             wearing, and can be directly installed with a buckle

Technical Parameter

   locate mode

    Beidou/GPS dual-mode positioning

   Positioning accuracy

    5m-50m

   Communication

    4G

   Ambient temperature

    -30℃-60℃

   Upload frequency

    Default upload once every 2 hours

   Endurance capability

    12 months

   Waterproof and dustproof

    IP67

   Volume weight

    86mm*50mm*43mm，168g

Function

Motion Monitoring
Built in motion sensor, capable of counting the number of steps taken by livestock during movement
Livestock Positioning
Adopting the Beidou/GPS dual-mode positioning module, it can accurately collect the location information of livestock under low-power conditions
